Eagle TT-4 - Accelerator Pedal Assembly Yanmar Tier II Engine

115
REV30 8.4.15 TT4-8 4TNV98
OPERATOR COMPARTMENT
Item Part Number Qty Description
1 A-TT4-00281-1 1 FOOT PEDAL ASSEMBLY
2 NPN 3 SCREW-HEX CAP-1/4-20 X 1.00 G8
3 NPN 3 WASHER-FLAT-1/4
4 NPN 3 NUT-LOCK-1/4-20
5 A-TT4-00285* 1 ACCEL CABLE BRACKET
6 A-TT4-00287 1 BALL JOINT KIT - NUT INCLUDED
7 A-TT4-00282-1 1 ACCELERATOR CABLE ASSEMBLY
8 A-TT4-00247 1 ACCELERATOR U-BOLT KIT
9 A-TT4-00283-1 1 ACCELERATOR CLEVIS-PIN KIT
ACCELERATOR PEDAL ASSEMBLY —YANMAR TIER II DIESEL
*TUG MODEL AND SERIAL NUMBER REQUIRED TO ORDER THIS PART
