Eagle TT-4 - Rear Axle Assembly

64
REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY— REAR (ALL TT 4-8 MODELS)
Item Part Number Qty Description
1 A-TT4-00361** 1 REAR AXLE ASSEMBLY
2 A-TT4-00116 2 LEAF SPRING
3 A-TT4-00362-1 4 U-BOLT KIT
4 A-TT4-00363 2 AXLE CLAMP PLATE
5 A-TT4-00366* 8 WASHER
6 A-TT4-00365* 8 NUT
7 4313905 1 LEFT HAND BACKING PLATE
8 4313904 1 RIGHT HAND BACKING PLATE
**CALL EAGLE TUGS FOR INFORMATION IF YOUR TUG IS EQUIPPED WITH LIMITED SLIP
AXLES
*INCLUDED IN U-BOLT KIT
