161
REV30 8.4.15 TT4-8 4TNV98
TRANSMISSION REFILL CAPACITIES
ENGINE U.S. PINTS IMPERIAL PINTS LITRES
3.3 L DIESEL 8.00 6.60 3.80
* USE DEXTRON III TYPE TRANSMISSION FLUID OR EQUIVALENT
**ADD 9 PINTS, 7.5 IMPERIAL PINTS OR 4.25 LITERS IF TORQUE CONVERTOR HAS BEEN DRAINED
ENGINE COOLING SYSTEM REFILL CAPACITIES
ENGINE U.S. QUARTS IMPERIAL QUARTS LITRES
3.3 L DIESEL 16.00 13.30 15.10
* A 50/50 MIXTURE OF GLYCOL AND CLEAN WATER
BRAKE SYSTEM
The brake system is power assisted hydraulic, front disc type and rear drum type. USE DOT 3 BRAKE FLUID.
STEERING FLUID AND FILL PROCEDURE
The steering system is power assisted hydrostatic type. Use Either Power Steering Fluid Equivalent Soec For GM
9985010, CHRYSLER MS-5931 OR FORD ESW-M2C128-C and D OR 10W Mineral Oil.
If the system has been drained for repair or scheduled maintenance, fill steering reservoir to within 2” of maximum
fill level. With the key in the OFF position, turn the engine over for 30 seconds using a remote start device to ensure
safety. While engaging the remote starter, turn the steering wheel from stop to stop and apply the service brakes.
After 30 seconds of engagement, the fluid level will drop, allowing for refilling. Repeat this process for a total of
three cycles. Top off power steering fluid to within 2” of top of reservoir or to the center of the sight glass (if appli-
cable). Return to service.
AXLE REFILL CAPACITIES
AXLE U.S. PINTS IMPERIAL PINTS LITRES
FRONT STEER – NON
DRIVE
N/A N/A N/A
FRONT DRIVE AXLE
5.20 4.37 2.48
REAR DRIVE AXLE 8.50 7.00 3.75
* SERVICE REFILL CAPACITIES ARE DETERMINED BY FILLING TO THE BOTTOM OF THE FILLER HOLE
**USE 80W90 HYPOID GEAR LUBRICANT
MAINTENANCE
TT4-8 DIESEL SPECIFICATIONS & CAPACITIES
