Eagle TT-4 - Page 27

27
REV30 8.4.15 TT4-8 4TNV98
CYLINDER BLOCK ASSEMBLY—YANMAR TIER II
Item Part Number Qty Description
1 22351-060012 2 SPRING PIN 6 X 12
2 129900-01250 1 PLUG 55
3 27241-300000 8 PLUG 30
4 23876-030000 3 PLUG PT 3/8 SCREW
5 129907-01190 1 SPACER
6 129900-02930 2 BEARING ASSY, THRUST
6 129900-02940 2 BEARING ASSY, THRUST O/S=.025
7 729900-02800 5 MAIN BEARING SET
7 129900-02340 5 MAIN BEARING SET O/S=.025
8 129900-02020 10 BOLT, METAL CAP
9 129900-02410 1 BUSH, CAMSHAFT
10 171051-01921 1 PLUG
11 129907-01331 1 CYLINDER HEAD GASKET
12 129900-01200 18 BOLT, HEAD
13 729907-01560 1 CYLINDER BLOCK ASSY, INC ITEMS 1-10
POWER TRAIN
