Eagle TT-4 - Page 33

33
REV30 8.4.15 TT4-8 4TNV98
CRANKSHAFT & PISTON—YANMAR TIER III DIESEL
Item Part Number Qty Description
1 129927-22050 4 RING SET STANDARD
1 729927-22950 4 RING SET O/S=0.25
2 129907-22080 4 PISTON WITH RING STANDARD
2 129907-22900 4 PISTON WITH RING STANDARD O/S=0.25
3 120130-22301 4 PISTON PIN
4 22252-000300 8 CIRCLIP 30
5 129900-23911 4 BUSH, PISTON PIN
6 129900-23601 4
BEARING ASSY, CRANKCASE PIN STANDARD
6 129900-23611 4 BEARING PIN O/S=.025
7 129900-23200 8 BOLT, ROD
8 129900-23001 4 CONNECTING ROD ASSY
9 129916-21610 1 BOLT, V-PULLEY
10 129900-21640 1 WASHER
11 129907-21660 1 V-PULLEY, CRANKCASE
12 129900-21220 1 GEAR, CRANKSHAFT
13 22512-070140 1 KEY 7 X 14
14 121850-21290 1 PARALLEL PIN
15 121850-21920 1 PARALLEL PIN 10 X 22
16 129902-21050 1 CRANKSHAFT ASSY INCLUDED ITEMS 12-15
17 129900-21600 1 RING GEAR
18 129953-21570 1 FLYWHEEL WITH RING GEAR
POWER TRAIN
