Eagle TT-4 - Page 43

43
REV30 8.4.15 TT4-8 4TNV98
GEAR HOUSING
Item Part Number Qty Description
1 24311-000070 1 O-RING 1A P7.0
2 977770-01212 3 GASKET, LIQUID
3 129900-26250 2 BALL BEARING
4 26106-080202 3 BOLT, M8 X 20 PLATED
5 26106-080452 3 BOLT, M8 X 45 PLATED
6 129900-32001 1 OIL PUMP ASSEMBLY
7 26106-080162 3 BOLT, M8 X 16 PLATED
8 129962-01500 1 CASE, GEAR
9 26216-100302 4 STUD, BOLT
10 26306-100002 4 NUT
11 24351-030750 1 PACKING, 3075
12 129900-32030 1 O-RING P20
13 129900-32040 1 O-RING P14
14 124160-01751 1 OIL FILLER CAP
15 24311-000320 1 O-RING 1A P32.0
16 129900-14140 1 BEARING #6205
17 129900-01870 1 SPONGE
18 129900-01850 1 COVER ASSEMBLY INCLUDES ITEM 20
19 26106-080402 10 BOLT M8 X 40 PLATED
20 129900-01740 1 COVER, FI PUMP
21 129001-91810 7 BOLT, M8 X 70 PLATED
22 129900-01780 1 SEAL, OIL
23 729907-01550 1 HOUSING ASSY COVER INCLUDES ITEM 25
24 129100-01580 4 PARALLEL PIN 8 X 16
25 26106-080162 3 BOLT, M8 X 16 PLATED
POWER TRAIN
