59
REV30 8.4.15 TT4-8 4TNV98
TRANSAXLE CASE EXTENTION & RETAINER (ALL TT 4-8 MODELS)
Item Part Number Qty Description
1 6501474 10 SCREW-HEX CAP-WASH M8-1.25 X 16
2 4471573 1 PAN
3 NPN 1 CUP(NOT SOLD SEPARATELY)
4 4504568 1 SPACER KIT
5 4269787 1 RETAINER, OIL
6 4329829 1 RETAINER, BEARING
6500368 6 SCREW-HEX CAP-M8 X 1.25 X 23
7 NPN 6 SCREW-HEX CAP-WASH HEAD M8-1.25 X 2
8 NPN 10 SCREW-HEX CAP M8-1.25 X 15
9 4659342 1 COVER, TRANS. END
82180 1 RTV SEALANT
6501474 10 SCREW-HEX CAP WASH M8-1.25 X 16
10 3878447 1 SEAL, MANUAL VALVE SHAFT
11 4471573 1 PAN, TRANSAXLE OIL
12 6501474 12 SCREW-HEX CAP WASH M8-1.25 X 16
6101285 1 SCREW-HEX CAP-WASH M6-1 X 16
13 4567022 1 CUP
14 4567494 1 RETAINER
15 6500111 1 O-RING
16 A-TT5D-00011-MOD 1 *TRANSMISSION CONE
6500511 4 SCREW-HEX CAP-WASH M8-1.25 X 33
17 NPN 2 M8 HEX HEAD SCREW
18 4412522 1 SEAL
19 NPN 1 BUSHING (SERVICED IN EXT.)
20 NPN 4 SCREW-HEX CAP WASH HEAD M8-1.25 X 30
21 A-TT4-00658 1 TRANS EXP PLUG
22 A-TT4-00657 1 TRANSMISSION PLUG (2WD ONLY)
TRANSMISSION
*PLEASE HAVE TUG MODEL AND SERIAL NUMBER AVAILABLE WHEN ORDERING THIS PART
