Eagle TT-4 - Page 69

69
REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY BREAKDOWN –FRONT NON-DRIVE (2WD)
Item Part Number Qty Description
1 29775-29X 1 TUBE ASSEMBLY
2 44101 2 NUT-SLOTTED
3 500024-8 2 PIN-COTTER
4 35417 2 RING-ADJUSTING
5 40112 1 SOCKET ASSEMBLY UPPER
6 35566 2 NUT-LOCK
7 40113 1 SOCKET ASSEMBLY LOWER
8 35928 1 RING-SNAP
9 31026-1 2 BOLT-STOP
10 500381-3 2 NUT-JAM
11 706652X KIT
STEERING KNUCKLE R/H
INCLUDES ITEMS 33-39 & 42
11 706653X KIT
STEERING KNUCKLE L/H
INCLUDES ITEMS 33-39 & 42
12 44101 2 NUT-SLOTTED
13 500024-6 2 PIN-COTTER
14 044TR115-16X 1 TIE ROD ASSEMBLY
15 36544 2 PLUG-CAP
16 38428 2 SPINDLE-WHEEL BEARING
17 35704 12 NUT-LOCK
18 36361 2 SEAL-LOCK
19 706690-X KIT INNER WHEEL BEARING
20 044HU103 2 HUB & ROTOR ASSEMBLY
21 706111-X KIT OUTER WHEEL BEARING
22 21588X 2 SPINDLE NUT
23 36569 2 LK WASHER-WHEEL BRG NUT
24 31139 2 NUT-SPINDLE
25 31552 2 CAP-HUB
26 36326-2 6 STUD STEERING KNUCKLE
N/S 044WC101-2 1 CALIPER ASSEMBLY R/H
N/S 044WC101-1 1 CALIPER ASSEMBLY L/H
N/S 044WB101-1 1 BRACKET ASSEMBLY-CALIPER L/H
N/S 044WB101-2 1 BRACKER ASSEMBLY-CALIPER R/H
27 610286 8 WHEEL STUDS
AXLES
Recommended tools:
OTC 7157 To remove Front Axle Spindle Nut (Dana 44)
OTC 7080 To remove Front Axle Top Ball Joint (Dana 44)
OTC 1902 To remove Front & Rear Axle Spindle Nut (Dana 70)
