Eagle TT-4 - Page 71

71
REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY BREAKDOWN—FRONT DRIVE (ALL WHEEL DRIVE)
AXLES
Item Part Number Qty Description
1 A-TT8-00371 1 COMPLETE AXLE ASSEMBLY
2 22404X 1 GEAR & PINION ASSEMBLY
3 30764 1 SLINGER-PINION OIL INNER
4 706031X KIT INNER PINION BEARING
5 706617X KIT
SHIM-PINION ADJ
INC ITEMS 5,7,12,13,15,15A
6 30765 1 BAFFLE-PINION OIL
7 706617X KIT SEE ITEM 5
8 706030 KIT OUTER PINION BEARING & RACE
9 13575 1 SLINGER-PINION OIL OUTER
10 39118 1 SEAL-OIL
11 345761X 1 END YOKE ASSEMBLY
12 30186 1 WASHER-PINION NUT
13 30185 1 NUT-PINION
15 82180 AR RTV SEALANT
16 34685 1 GASKET
17 36472 1 PLUG-COVER PLATE
18 34279 10 SCREW-FLANGE HD
19 N/A 2
CAP DIFFERENTIAL BEARING
NOT SERVICED SEPERATELY
20 48632-1 2 1/2-13 X 2.25 GRD8 HEX BOLT
21 706032X KIT DIFFERENTIAL BEARING & RACE
22 706618X KIT DIFFERENTIAL SHIM INC ITEMS 22,15 &15A
23 25806X 1 CASE-DIFFERENTIAL ASSY
32684 1 CASE-DIFFERENTIAL
24 41221 10 BOLT-DRIVE GEAR
25 17717 2 PINION-DIFFERENTIAL
26 706027X 2 GEAR-DIFF KIT INC ITEMS 15A & 24-29
27 13338-3 2 THRUST WASHER DIFFERENTIAL PINION
28 32121 2 THRUST WASHER DIFFERENTIAL GEAR
29 39194 1 SHAFT-DIFFERENTIAL
30 13449 1 PIN-ROLL
31 16979 1 VENT
32 36352 2 SEAL & GUIDE-SHAFT
33 44101 2 NUT-SLOTTED
34 500024-8 2 PIN-COTTER
35 35417 2 RING-ADJUSTING
36 40112-1 1 SOCKET ASSEMBLY-UPPER
37 35566 2 NUT-LOCK
38 40113-1 1 SOCKET ASSEMBLY-LOWER
39 35928 1 RING-SNAP
