REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY BREAKDOWN—FRONT DRIVE (ALL WHEEL DRIVE)
Item Part Number Qty Description
40 310026-2 2 BOLT-STOP
41 500381-3 2 NUT-LOCK
42 706653X KIT STEERING KNUCKLE L/H, INCLUDES ITEMS 33-39,42 & 53
42 706652X KIT STEERING KNUCKLE R/H, INCLUDES ITEMS 33-39,42 & 53
43 44101 2 NUT-SLOTTED
44 500024-4 2 PIN-COTTER
45 044TR115-16X 1 TIE ROD ASSEMBLY
46 660091-18 2 SHAFT & JOINT ASSY INC ITEM 47
47 36364 1 SLINGER
48 38128 2 SEAL-OIL
49 38106 2 SPACER
50 550759 2 BEARING-NEEDLE
51 044TR119 2 TIE ROD END ONLY FOR ITEM 45
52 500381-3 12 NUT-LOCK FOR ITEM 53
53 36326-2 12 STUD FOR ITEM 42
57 21588X 2 SPINDLE NUT
58 36569 2 LOCK-RETAINING NUT
59 31139 2 NUT-SPINDLE
62 31624 2 RING-SNAP
68 31552 2 CAP-HUB
69 42667 2 GEAR-AXLE DRIVE
70 35218 2 SPRING PRESSURE
71 32589 2 PLATE-SPRING RETAINING
72 706111X KIT OUTER WHEEL BEARING & RACE
73 044HU103 2 HUB & ROTOR ASSEMBLY
74 706690-X KIT INNER WHEEL BEARING & RACE
75 36366 2 AXLE SEAL
76 706570 KIT SPINDLE ASSEMBLY INCLUDES ITEMS 48,49,50,77 & 76
706527X KIT SPINDLE SEAL & BEARING INCLUDES ITEMS 50,77,48 & 49
77 36361 1 SEAL-OIL
78 RD52 1 SET BRAKE PAD SET
79 18009659 1 CALIPER WITHOUT PADS -R/H
79 18009658 1 CALIPER WITHOUT PADS-L/H
79 044WC101-1 1 CALIPER ASSY WITH PADS L/H
79 044WC101-2 1 CALIPER ASSY WITH PADS R/H
80 5468226 1SET ANCHOR BOLTS
81 5-297-1X 2 GREASABLE U-JOINT FOR ITEM 46
82 H5539 1 CALIPER BUSHING AND O-RING KIT
83 BD60427 2 ROTOR
