Eagle TT-4 - Page 75

75
REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY BREAKDOWN—REAR DRIVE
AXLES
Item Part Number Qty Description
A-TT4-00361 1 COMPLETE AXLE ASSEMBLY
2 706033-10X KIT DRIVE GEAR & PINION
3 706046X KIT INNER PINION BEARING & RACE
4 706672X KIT SHIM-DRIVE PINION ADJUSTING
5 30765 1 BAFFLE-PINION BEARING
6 706672X KIT SHIM-PINION BEARING ADJUSTING
7 706045X KIT OUTER PINION BEARING & RACE
8 30273 1 SLINGER-PINION BEARING
9 38427 1 SEAL-PINION
10 345731X 1 END YOKE ASSEMBLY
11 30275 1 WASHER-PINION NUT
12 30271 1 NUT-PINION
14 73597 1 COVER ASSEMBLY
15 82180 RTV SEALANT
15a 39697 1 COVER GASKET
16 98785 1 PLUG-PIPE SLOTTED
17 34822 10 SCREW-FLANGE HD
18 39697 1 AXLE SHAFT GASKET
19 48632-1 2 1/2-13 x 2.25 GRD8 BOLT BEARING CAP
20 706047X KIT BEARING & RACE
21 706673X KIT SHIM-DIFFERENTIAL BEARING
22 706669X KIT CASE-DIFFERENTIAL
23 30266 10 BOLT-DRIVE GEAR
24 SEE KIT ITEM 43 OR 44 KIT PINION-DIFFERENTIAL
25 SEE KIT ITEM 43 OR 44 KIT GEAR-DIFFERENTIAL
26 SEE KIT ITEM 43 OR 44 KIT THRUST WASHER-PINION
27 SEE KIT ITEM 43 OR 44 KIT THRUST WASHER-GEAR
28 SEE KIT ITEM 43 OR 44 KIT SHAFT-DIFFERENTIAL
29 500598-21 1 LOCK-DIFFERENTIAL
30 36253 8 BOLT-BRAKE MANUFACTURING
31 36805 8 NUT-BRAKE MANUFACTURING
32 36240 2 SEAL-OIL
33 706071X KIT INNER WHEEL BEARING
34 706072X KIT OUTER WHEEL BEARING
35 36241 2 HUB & DRUM ASSEMBLY
36 36847 8 STUD-HUB
