77
REV30 8.4.15 TT4-8 4TNV98
AXLE ASSEMBLY BREAKDOWN—REAR DRIVE CONT
AXLES
Item Part Number Qty Description
37 30636 4 NUT-SPINDLE
38 30637 2 LOCK WASHER WHEEL BEARING
39 34887-7 1 SHAFT-AXLE FLANGE LONG
34887-10 1 SHAFT-AXLE FLANGE SHORT
40 31534 16 ADAPTER-STUD
41 36805 24 NUT-LOCK
42 16979 1 VENT
43 706671X 1 DIFF PARTS (STD) INC 15, 21-23, 29
44 707084X 1
DIFF PARTS (LTD SLIP) INC 15, 21, 23, 24, 26,
28, 29, 43
