REV30 8.4.15 TT4-8 4TNV98
PARKING BRAKE ACTUATOR ASSEMBLY
Item Part Number Qty Description
1 A-TT4-00141 1 HAND BRAKE
2 NPN 4 SCREW-HEX CAP-5/16-18 X 1
3 NPN 4 WASHER-FLAT-5/16
4 NPN 4 NUT-LOCK-5/16-18
5 B-TT4-00145 1 CABLE PRIMARY
6 A-TT4-00146 1 BAR EQUALIZER
7 A-TT4-00193 3 CLEVIS PIN
8 NPN 3 COTTER PIN
9 A-TT4-00151 1 PARKING BRAKE CABLE LEFT REAR
10 A-TT4-00150 1 PARKING BRAKE CABLE RIGHT REAR
11 NPN 1 SCREW-HEX CAP-14-20 X 1
12 NPN 1 WASHER-FLAT-1/4
13 NPN 1 NUT-LOCK-1/4-20
14 NPN 1 SCREW-HEX CAP-1/4-28 X 1
15 NPN 1 CABLE CLAMP PLATE
16 NPN 1 CABLE CLAMP HANDLE
17 NPN 2 NUT-LOCK-1/4-28
18 NPN 2 CABLE CLAMP
19 81008429 1 CONTACT PIN
20 82050000 1 PROXIMITY SENSOR
21
82066700 1 MOUNTING SCREW (NOT SHOWN)
22 AE-OPT-0069 1 HAND BRAKE "ON" WARNING (OPTIONAL)
