Eagle TT-4 - Page 81

81
REV30 8.4.15 TT4-8 4TNV98
BRAKES
DRUM BRAKE ASSEMBLY—REAR
Item Part Number Qty Description
060WD101 1 BRAKE ASSEMBLY R/H
060WD100 1 BRAKE ASSEMBLY L/H
1 4313905 1 BACKING PLATE L/H
1 4313904 1 BACKING PLATE R/H
2 FR357 1 SET SHOE & LINING SET
4 2235585 1 CYLINDER ASSEMBLY L/H
4 2235586 1 CYLINDER ASSEMBLY R/H
5 315834 2 WHEEL CYLINDERS CONNECTING LINK
6 *SEE KIT BELOW 1 COVER
7 *SEE KIT BELOW 1 SPRING-UPPER
8 *SEE KIT BELOW 1 SPRING-LOWER
9 *SEE KIT BELOW 2 SPRING-HOLD DOWN
10 *SEE KIT BELOW 1 PIN
11 *SEE KIT BELOW 1 SPRING TENSION
12 *SEE KIT BELOW 1 BRAKE ADJUSTING LINK
13 *SEE KIT BELOW 1 CABLE GUIDE
14 *SEE KIT BELOW 1 CABLE ASSEMBLY
15 *SEE KIT BELOW 2 SPRING-HOLD DOWN
19 4383299 1 PARKING BRAKE CAM L/H
19 4383298 1 PARKING BRAKE CAM R/H
20 4383264 1 PARKING BRAKE LEVER (RIGHT)
20 4383265 1 PARKING BRAKE LEVER (LEFT)
21 4419698 1 BRAKE ANCHOR BOLT
24 *SEE KIT BELOW 1 BRAKE ADJUSTING SOCKET L/H
25 *SEE KIT BELOW 1 BRAKE ADJUSTING SCREW L/H
26 *SEE KIT BELOW 1 BRAKE ADJUSTING SOCKET
27 *SEE KIT BELOW 1 WASHER FLAT
28 3492670 1 WASHER
29 3492656 1 SPRING
30 4383600 1 SPACER
KIT H2588 LEFT
BRAKE ADJUSTING KIT INCLUDES
ITEMS 6,10-14,20,24-27
KIT H2589 RIGHT
BRAKE ADJUSTING KIT INCLUDES
ITEMS 6,10-14,20,24-27
KIT H7146
LEFT OR
RIGHT
BRAKE SPRING KIT INCLUDES
ITEMS 7-9 & 15
**KIT PARTS NOT SOLD SEPERATELY
