Eagle TT-4 - Page 83

83
REV30 8.4.15 TT4-8 4TNV98
BRAKE ACTUATOR ASSEMBLY
* Welded to truck
BRAKES
Item Part Number Qty Description
1 NPN 4 ¼-20 SET SCREW
2 NPN 2 ½-20 NUT
3 C-TT4-10188 3 THOMSON NYLINER BEARING
4 C-TT4-10186 1 BELL CRANK
5 C-TT4-10187 1 BELL CRANK PIVOT SHAFT
6 A-TT4-00193 3 CLEVIS PIN
7 NPN 3 COTTER PIN
8 A-TT4-10192 3 CLEVIS
9 NPN 1 ½-20 X 12 ADJUSTING ROD
10 C-TT4-10182 1 BRAKE PEDAL PIVOT SHAFT
11 C-TT4-10181 1 BRAKE PEDAL
12 NPN 1 BRAKE PEDAL PIVOT
13 NPN 2 BELL CRANK STANDOFF
14 A-TT2-0057* 2 SHAFT COLLAR 3/4
15 NPN 3 CLEVIS PIN WASHER
