87
REV30 8.4.15 TT4-8 4TNV98
HYDRAULIC ASSIST SYSTEM WITH PRINCE PUMP
Item Part Number Qty Description
1 F81Z3A697BB 1 RESERVOIR POWER STEERING FLUID (REPLACED BY TT00-09-002-AA)
2 SP20PB11L145H9L 1 PRINCE PUMP
3 A-TT4-00161-1 1 MASTER CYLINDER
4 A-TT4-00381 1 STEERING GEAR BOX
5 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 110"
6 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 126"
7 NPN 6 # 4 HOSE CLAMP
8 A-TT4-00213 1 METRIC PORT ADAPTER
9 A-TT4-00204 1 RETURN LINE EXTENDER
10 06U-666-23-06U-B66 1 HYDRAULIC HOSE
11 06U-B67-56-06U-606 1 HYDRAULIC HOSE
12 A-TT4-00606-1A
3
FITTING MALE COUPLING
13 A-TT4-00606-1
1
Y FITTING BLACK IRON
14 12GMV MEGA VAC 1 3/4 SUCTION HOSE 24"
15 12GMV MEGA VAC 1 3/4 SUCTION HOSE 3"
16 12GMV MEGA VAC 1 3/4 SUCTION HOSE 21"
17 NPN 6 #12 HOSE CLAMPS
18 C3269X12X8 1 FEMALE PIPE ADAPTER
19 269HB-12-8 1 ELBOW 3/4 X 1/2
20 C5515X6 1 FITTING, ELBOW 3/8 X 3/8
21 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 48"
22 05TB-12-12 1 12 SAE ORB M, .75 HOSE BARB
HYDRAULIC ASSIST
