Eagle TT-4 - Page 89

89
REV30 8.4.15 TT4-8 4TNV98
HYDRAULIC ASSIST SYSTEM WITH METARIS PUMP
Item Part Number Qty Description
1 F81Z3A697BB 1 RESERVOIR POWER STEERING FLUID (REPLACED BY TT00-09-002-AA)
2 V10F1T3T11C3F20L 1 METARIS PUMP
3 A-TT4-00161-1 1 MASTER CYLINDER
4 A-TT4-00381 1 STEERING GEAR BOX
5 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 100"
6 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 114"
7 NPN 9 # 4 HOSE CLAMP
8 A-TT4-00213 1 METRIC PORT ADAPTER
9 A-TT4-00204 1 RETURN LINE EXTENDER
10 06U-666-23-06U-B67 1 HYDRAULIC HOSE
11 06U-B67-56-06U-606 1 HYDRAULIC HOSE
12 A-TT4-00606-1A
3
FITTING MALE COUPLING
13 A-TT4-00606-1
1
Y FITTING BLACK IRON
14 12GMV MEGA VAC 1 3/4 SUCTION HOSE 20"
15 12GMV MEGA VAC 1 3/4 SUCTION HOSE 3"
16 12GMV MEGA VAC 1 3/4 SUCTION HOSE 21.5"
17 NPN 6 #12 HOSE CLAMPS
18 4601-12-08 1 1/2 M SAE 3/4 SUCTION BARB 90 DEG FITTING
19 7033X14X12 1 7/8 M SAE 3/4 F SAE FITTING
20 25TB-12-12 1 3/4 M SAE 3/4 SUCTION BARB 90 DEG FITTING
21 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 20"
22 C5515X6X8 1 1/2 M SAE M JIC 37 FITTING
23 05706B-104 4 FITTING 3/8 X 1/4
24 A-TT4-00280 2 BULKHEAD FITTING
25 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 36"
26 10506B-108 2 FITTING, PUSH ON 06 TO 1/2M
27 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 33"
28 NPN 1 1/4 LOCK WASER
29 NPN 1 1/4-20 X 3/4 BOLT
30 4312-06-08 2 STRAIGHT BARB 1/2"
31 SAF-05-25-0 1 FILTER HEAD
32 SF-6520 1 FILTER ELEMENT
33 H10106 1 3/8 HYDRAULIC HOSE WK PSI 350 33"
HYDRAULIC ASSIST
