Eagle TT-4 - Page 95

95
REV30 8.4.15 TT4-8 4TNV98
STEERING SYSTEM BREAKDOWN
Item Part Number Qty Description
1 A-TT4-00381 1 STEERING BOX
2 NPN 4 SCREW-HEX CAP-7/16-14 X 2 GR8
3 A-TT4-00382 1 PITTMAN ARM
4 NPN 1 WASHER-LOCK-3/4
5 NPN 1 NUT-LOW-3/4-10
6 A-TT4-00386 1 DRAG LINK
7 NPN* 2 COTTER PIN 1/8 X 1 ½
8 NPN* 2 NUT-TIE ROD ½-20
9 A-TT4-00389 1 UNIVERSAL COUPLER
10 A-TT4-00390 1 SHAFT COUPLING
11 A-TT4-00391 1 UNIVERSAL JOINT
12 NPN 2 LOCKING BOLT-DOG POINT 3/8-16
13 A-TT4-00393 1 GIBB KEY
14 A-TT4-00394-1 1 STEERING SHAFT
15 A-TT4-00395 2 BEARING
16 A-TT4-00396 2 2 1/8 U-BOLT 3/8HD
17 NPN** 4 WASHER-FLAT-5/16
18 NPN** 4 NUT-LOCK-5/16-18
19 A-TT4-00399-1 1 STEERING WHEEL
20 N/A 1 SCREW-HEX CAP-3/8-24 X 1
21 A-TT4-00401-1 1 COVER PLATE
22 A-TT4-00402 1 TIE ROD END L/H
23 A-TT4-00403 1 TIE ROD END R/H
24 A-TT4-00404 1 STEERING TUBE
25 A-TT4-00405 4 SPACERS
26 A-TT4-00406 1 3/4-16 NUT-JAM-L/H
27 A-TT4-00407 1 3/4-16 NUT-JAM-R/H
28 A-TT4-00212 1 HIGH PRESSURE EXTENDER
29 A-TT4-00204 1 RETURN LINE EXTENDER
30 TT08-12-001-SA 1 STEERING SHAFT ASSEMBLY (REPLACES ITEMS 9-12)
STEERING SYSTEM
*ITEMS 7 & 8 NOT SOLD SEPERATELY. THESE PARTS ARE INCLUDED IN ITEMS 22 & 23
**ITEM 17 & 18 ARE INCLUDED IN ITEM 16
