REV30 8.4.15 TT4-8 4TNV98
FUEL SYSTEM
Item Part Number Qty Description
1 A-TT4-00273-1 1 FUEL TANK
2 A-TT4-00272 1 PIPE NIPPLE, 2 NPT X 5.5 LONG
3 A-TT4-00271-1 1 FUEL CAP, DIESEL
4 A-TT4-00276-1 1 FUEL SENDING UNIT
5 05705B-C04 5 ELBOW, 1/4 NPT X 5/16 BARB, BRASS
6 NPN 12 SAE HOSE CLAMP
7 H05705 1 5/16 FUEL HOSE, SAE30R7, 14" LONG
8 H05705 1 5/16 FUEL HOSE, SAE30R7, 17" LONG
9 05705B-104 1 HOSE BARB, 1/4 NPT X 5/16 BARB, BRASS
10 A-TT4-00280 2 BULKHEAD FITTING, 1/4 NPT
11 H05705 1 5/16 FUEL HOSE, SAE30R7, 21.5" LONG
12 H05705 1 5/16 FUEL HOSE, SAE30R7, 15" LONG
13 H05705 1 5/16 FUEL HOSE, SAE30R7, 44" LONG
14 129424-55700 1 FUEL-WATER SEPARATOR ASSEMBLY
15 129242-55730 1 REPLACEMENT ELEMENT
16 119225-52102 1 FUEL TRANSFER PUMP
17 H05705 1 5/16 FUEL HOSE, SAE30R7, 17" LONG
18 NPN - ON-ENGINE FUEL CONNECTION POINT
19 NPN 1 LUBRICITY FILTER BRACKET
20 FS20000 1 LUBRICITY FILTER ELEMENT
21 H05705 1 5/16 FUEL HOSE, SAE30R7
22 H05705 1 5/16 FUEL HOSE, SAE30R7
23 05705B-C04 5 ELBOW, 1/4 NPT X 5/16 BARB, BRASS
24 222P-4-M112 2 BRASS FITTING, 1/4" NPT X M12X1.5
25 NPN 4 M8 X 1.25 X 30 BOLT
26 NPN 4 5/16 FLAT WASHER
27 NPN 4 8MM SPLIT LOCK WASHER
