EASYPRINT Compact 53C - Communicator II Printer Main Parts; Printer Connections (Rear View); Printer Unit (Front View)

DESCRIPTION AND INSTALLATION
2-8 25364 Issue 8 March 2018
Communicator II Printer Main Parts
Printer Unit (Front View)
Cassette
Handle
Status
LED
Printer Connections (Rear View)
Secure Digital Flash Card SlotUSB Mini Connector
Sliding
Shutter
Air Pressure
Gauge
Air Pressure
Regulator
Communication ConnectorPower Supply Connector
Air Outlet
Air Inlet
USB Standard
Connector
