Eaton easyControl EC4-200 User Manual

Appendix
10/10 MN05003003Z-EN
100
Relay outputs
Number of outputs 6
Parallel switching of outputs to increase performance
Not permissible
Protection of an output relay
Miniature circuit-breaker B16 A
16
or fuse (slow-blow) A
8
Electrical isolation
Yes
Safe isolation V AC
300
Basic insulation V AC
600
Mechanical lifespan Switch
operations
10 x 106
Contacts relays
Conventional therm. current A 8
Recommended for load at 12 V AC/DC mA
> 500
Protected against short-circuit cos v = 1
Characteristic B (B16) at 600 A
A
16
Protected against short-circuit cos v = 0.5 bis 0.7
Characteristic B (B16) at 900 A
A
16
Rated impulse withstand voltage U
imp
contact coil kV
6
Rated insulation voltage U
i
Rated operational voltage U
e
V AC 250
Safe isolation to EN 50178 between coil and contact V AC
300
Safe isolation to EN 50178 between two contacts V AC
300
Making capacity, IEC 60947
AC-15 250 V AC, 3 A (600 Ops/h) Operation
s
300000
DC-13 L/R F ??0 ms 24 V DC, 1 A (500 Ops/h) Switch
operations
200000
Breaking capacity, IEC 60947
AC-15 250 V AC, 3 A (600 Ops/h) Switch
operations
300000
DC-13 L/R F 150 ms 24 V DC, 1 A (500 ops/h) Switch
operations
200000
Filament bulb load
1000 W at 230/240 V AC Switch
operations
25000
500 W at 115/120 V AC Switch
operations
25000
Fluorescent tube load, 10 x 58 W at 230/240 V AC
Fluorescent tubes
- with ballast
- with conventional compensation
- uncompensated
Switch
operations
25000
