Technical data
99
Delay time from 0 to 1
I1 to I4 ms 0.02
I5 to I12 ms
0.25
Delay time from 1 to 0
I1 to I4 ms 0.02
I5 to I12 ms
0.25
Cable length (unshielded) m
100
Additional input functions
Inputs for analog signals
Number 4 (I7, I8, I11, I12)
Signal range V DC
0 to 10
Resolution, analog V
0.01
Resolution, digital Bit
10
Value
0 to 1023
Input impedance kO
11.2
Accuracy of actual value
Two devices % g 3
Within a single device %
g 2
Input current mA
< 1
Cable length (shielded) m
30
Inputs for high-speed counters
I 1, I2
Number/value range Bit
2 x 16 bit (I1,I2)
1 x 32 bit (I1)
Max. frequency kHz
50
Count direction selectable via software
incrementing/decrementing
Cable length (shielded) m
20
Pulse shape
Square
Mark-to-space ratio
01:01
Incremental counter
I1, I2, I3, I4
Quantity
1
Value range Bit
32 Bit
Max. frequency kHz
40
Cable length (shielded) m
20
Pulse shape
Square
Counter inputs
I1,I2 = Counter input
I3 = Reference pulse
I4 = Reference window
Signal offset
90°
Mark to space ratio
01:01
Inputs for interrupt generation
I1, I2, I3, I4
Max. frequency kHz
3
