P.18
PM10U
EBARA
CORPORATION
2.4.2 Specifications
Table 2.1 Specification
MODEL EV-A10
Model
EV-A10-2*
(1Phase 200V)
EV-A10-3*
(3Phase 200V)
Maximum 1,000 L/min Pumping
Speed
Atmospheric 800 L/min
Gas ballast : OFF 1.0 Pa
Ultimate
Pressure
[note 1]
Gas ballast : ON 2.0 Pa
Maximum Inlet Pressure Atmospheric
Maximum pure water vapor tolerance
[note 2]
500 g/hr
Gas Inlet NW40
Connection
Gas Outlet NW40
at Ultimate Pressure 1.1 kW
Approx.
Power
Maximum 1.3 kW
Brand, Manufacturer BARRIERTA J100ES, NOK
Lubrication
oil
Quantity 90 mL
Approx. Weight 75 kg
Inlet Voltage [50/60 Hz] 1Phase / 200-240 V 3Phase, 200-240 V
Allowable Voltage
Fluctuation
+/- 10 %
Allowable Frequency
Fluctuation
+/- 5 %
Power Capacity 3.0 kVA
Power
Supply
Connection IEC 60320-C20
Amphenol
C016 20C003 100 12
Circuit Protector Rating 16 A 15A
Control Signal D-sub 15Pin
Cooling System Air Cooling
Ambient Temperature 5 to 40 deg C
[note 1] The gas ballast port is equipped with the model “EV-A10-*S”,
or chosen option of the model “EV-A10-*U”.
[note 2] It is an amount of the maximum processing when the gas ballast is “ON”.
