4.2 Operation Panel Display
The information of the pump or the ALARM status is displayed on the data screen of the operation
panel.
RE/LO LED is lighting in Local mode.
NOTE
Do not push , or the inverter settings might be changed. Push button
several times to come back to status screen, if the screen shows information other than
above. If the setting is changed, the pump specification or control system can’t be
guaranteed.
Target speed [min
]
DRV lamp lighting
DRV lamp lighting
Driving speed [min
]
DRV lamp/FOUT lamp lighting
Motor current [A]
DRV lamp lighting
Total running time [ x10 hour]
DRV lamp lighting
Data screen blinking
Data screen blinking
CP ON
