P.38
PM10U
EBARA
CORPORATION
5.2 START / STOP
The control mode can be set Local/Remote at any time by LO/RE button. (See Fig. 5.1)
After stopping the pump, set in accordance with the operating conditions.
a) START
【
【【
【LOCAL MODE】
】】
】
Push and select “LOCAL MODE”.
After checking that the LO/RE lamp is ON, push .
The pump will start and the RUN lamp will be ON.
【
【【
【REMOTE MODE】
】】
】
Push , select “REMOTE MODE” .
After checking that the LO/RE lamp is OFF, input RUN signal from the control connector.
(See table 3.1)
The pump will start and the RUN lamp will be ON.
[NOTE] All buttons are on the operation panel.
[NOTE] The pump will not start when an ALARM has been generated.
[NOTE] The control mode can not be selected during RUN lamp is ON.
WARNING
The pump starts immediately after the inverter on-delay time if the CP turns on with
remote RUN signal in Remote mode. Make sure the pipings are connected properly.
Execute the safety preparations against sudden start the pump.
！
！！
！
CATION
If the pump does not start smoothly, the exhaust gas may be backstreaming from the
outlet port. Please check the system condition and retry the start process.
！
！！
！
Push
LOCAL
MODE
REMOTE
MODE
Fig. 5.1 Switching Between LOCAL and REMOTE
