P.43
PM10U
EBARA
CORPORATION
(2) After you have waited until the internal pump pressure returns to atmospheric (normal) pressure,
remove the plug from the oil-inlet. (See Fig. 6.4)
(3) Check the oil level from the sight-glass of the oil level gauge. Then add the lubricant oil so that the
level is the upper level. (See Fig. 6.2 and 6.4)
(4) After you have checked that there are no depositions and fragments adhering to the O-ring
attached to the plug, close the oil-inlet.
(5) Be sure to check the gas leak after supplying the lubricant oil.
WARNING
Be sure only to use the lubricant oil listed in specification table 6.1
！
！！
！
WARNING
When the lubrication oil level exceeds the upper limit, the oil may leak to the pump side.
Thus, be sure no to exceed the upper limit line when adding the oil.
！
！！
！
Oil filler Inlet Oil level gauge
Oil drain port
Fig. 6.4 oil filler inlet, oil level gauge, and oil drain port positions
WARNING
Waste oil shall be disosed of by industrial waste disposal dealer in accordance with
Material Safety Data Sheets. (Appendix 1, 2)
！
！！
！
WARNING
The pump casing, inlet piping and exhaust piping become extremely hot during
operation and for some time after stopping. Be sure that pump and exhaust piping do
not come in contact with humans or inflammable substances. Do not remove the pump
cover during operation.
！
！！
！
