3 Menu 2-3 - Pack controllers
List of all available pack controllers in the E*LDS system. If a pack controller is selected, the
following information can be retrieved via the corresponding screen: node and position designations, message
priority, CAN bus address, serial number, firmware version, "Integrated via" (connected to CAN bus terminal)
andpacknumber(designationofthepack).
Diverse statuses and operating states are also displayed.
Symbol Meaning
The status of the connection (communication) with the node is OK
The status of the connection (communication) with the node is unknown
The node has failed
The node has been unloaded
The status of the node is OK
The node has alarm status
Remote control using terminal mode
Tapping the Remote Control button opens the terminal mode screen. In the terminal mode, all parameters of
the pack controller can be viewed, but not changed (read-only). For more information, see chapter Remote
control of E*LDS components (terminal mode).
The pack controller is configured in Menu 4-3.
