4 Menu 2-4 - Receiver Module Wireless Sensors
List of all available receiver modules for wireless sensors in the E*LDS system. If a receiver module
is selected, the following information can be retrieved via the corresponding screen: node and position
designations, message priority, CAN bus address, serial number, firmware version, "Integrated via" (connected
to CAN bus terminal) and pack number ( (membership of pack x). The assigned CAN bus address, diverse
statusesandoperatingstatusesarealsodisplayed.
Symbol Meaning
The status of the connection (communication) with the node is OK
The status of the connection (communication) with the node is unknown
The node has failed
The node has been unloaded
The status of the node is OK
The node has alarm status
Remote control using terminal mode
Tapping the Remote Control button opens the terminal mode screen. In the terminal mode, all parameters of
the receiver module including the associated wireless sensors can be viewed, but not changed (read-only). For
more information, see chapter Remote control of E*LDS components (terminal mode).
The receiver module including the associated wireless sensors is configured in Menu 4-4.
