Other
The mode of operation of the multi-function relay AUX is configured using this entry screen. For further
information, see chapter Modem hardware reset, page 46.
The screen contains the following parameters:
Alarm signalling other Entry Default
AUX relay
Function XXX The multi-function relay AUX must be set to
PRIOX3, .. or PRIOX9 so that it can be used as
alarm relay!
For details about the configuration, chapter
Multi-function relay AUX, page 30.
Horn,
alarm relay PrioX3,
PrioX4, PrioX5, PrioX6,
PrioX7, PrioX8, PrioX9
Modem reset
GLT modem changeover
Horn
Alarm relay stop Stop alarm relay PRIO1/PRIO2:
Y: Relays are only deactivated when the cause
for the alarm has been rectified and the alarm
has been acknowledged
N: Relays are deactivated when the horn is
switched off
Y/N Y
Test alarm
Message text XXX Message text of the test alarm - Test alarm
Priority XXX Message priority of the test alarm 1..99 1
Test alarm trip Button for tripping the test alarm - -
It must be checked before the configuration of the multi-function relay AUX that no conflict with the
existing configuration / wiring is produced by the change of the settings.
For example, a possible conflict could be that a horn is already connected to the multi-function relay
AUX and is used for audible alarm signalling!
