C3A, C6A, C6A HDVideoColposcope User ManualApplication of the Video Colposcope Software
- 45 -
Figure 5-17
The coordinate helps to locate the center of an image, facilitating image capturing. Pull the
trigger again, the coordinate disappears.
If the camera handle trigger is set to capture image, you can pull this trigger to capture the current
image.
5.4.3 Taking Video
Click the Videotag , the system starts taking video.Click the Stoptag
to stop taking video. The video taking can last for at most one hour. Once one
hour is reached, the system automatically stops taking video.
The video is saved as an .avi file and the file is shown with a video symbol on the right of the
screen. You can double-click to playthe video and capture images during video playing.
5.4.4 Viewing in FullScreen Mode
Double-click on the image observation area,itzooms in to occupy the whole screen.Double-click
on the screen or press the Esc button to exit full screen mode.
