MINUTEMAN 320
133
REV 13.1:2020
F3 System Function
Setting unit Range Suggested setup
Normal / Latch Normal / Latch Normal
Description:
Feed Stop
Latch/Normal
Setting method:
Note:
When lathe collet opens normal setting allows bar feeder to feed. When
latch is set bar feeder must receive a signal from lathe when collet is
open.
Set normal to feed when collet opens. Set latch to feed when collet is
open and the lathe commands the feed stop.
Setting unit Range Suggested setup
Feed / Do Not
Feed
Feed / Do Not Feed Feed
Description:
Do Not Feed After
EOB
Setting method:
Note:
When the end of bar signal is sent to the lathe the bar feeder will or will
not feed once the lathe collet opens.
Select feed or do not feed in the parameter.
