MINUTEMAN 320
144
REV 13.1:2020
Alarm 94
Cannot Go Into Auto While The
Collet is Open
Close the lathe collet
Alarm 95
Hood Not closed while Operating
Channel
Close the hood
Alarm 96
Hood Not Closed During Insertion
or Extraction
Close the hood
Alarm 97
Hood not closed During Gripper
Actuation
Close the hood
Alarm 98 Hood Not closed During Bar Load Close the hood
Alarm 99
Movement Detected During Collet
Open
Bar feeder detected stock movement beyond
pushback distance
Alarm 100 Bar Jammed
Remove bar following bar removal procedure.
Check for obstruction in bar path.
Alarm 101
Channel Must Be Open To Enter
Auto
Open the channel
Alarm 102 Bar Detected By Front Proximity
Bar detected
Alarm103 Extraction Failure
Check for pusher collet condition
Alarm104 Extraction Failure
Check for pusher collet condition
