2.6.2 Electrical Connection
Warning The power for the bar feeder and the input and output signals between the
bar feeder and lathe are supplied through the interface cable. The interface cable is normally
pre-wired for the lathe application when shipped from Edge. The installer should verify the
connection to the lathe before applying voltage to the system. If the lathe is not equipped with
an interface connection for the machine plug and cables will be supplied. This supplied harness
must be wired into the lathe electrical cabinet by a qualified technician. The lathe must support a
machine type interface for the machines to be connected. Additionally some lathes types power
output may be higher than the required 230 voltage. If this is the case an additional transformer
will be required to step down the lathe voltage for the bar feeder.
*Note the wiring interface contained in this manual is a generic 1 to 1 pin to wire call out.
Each lathe brand is different from one to another. Please contact Edge Technologies for
the proper interface schematic if you do not have one.
