MINUTEMAN 320
53
REV 13.1:2020
4.14 Installation Components
Spindle Liner: Used to reduce spindle diameter to support the pusher. Some applications do
not require a spindle liner. This is true when the spindle bore diameter is the same as the
pusher.
Fixed front nose and insert: This nose is cut to fit and used on fixed headstock lathes. If
multiple inserts.
Telescopic front nose: The telescoping nose is normally used with sliding headstock lathes
and attaches from the bar feeder to the MAVD when equipped. This nose is normally cut to
provide room for the MAVD and keep the nose from collapsing into itself. Additionally there is a
spacing ring that is required for the nose to be fastened to the MAVD.
Movable anti – vibration Device (MAVD): Used only on Swiss type lathes, The MAVD is
fixed at the end of the spindle of the lathe. The device aids in material support between the
headstock and bar feeder. This is always installed unless a special condition is present that
would keep the pusher from reaching the required maximum pusher travel. Contact Edge
Technologies for more information. Swiss lathe applications only.
Synchronization connecting rod: Synchronization rod is connected at the MAVD. Swiss
applications only.
Oil tray drip pan: This is used under the telescoping nose to collect any oil that leaks out of the
telescoping nose and back into the bar feeder. Swiss applications only.
Oil Gathering: Used on fixed headstock applications only.
