MINUTEMAN 320
10
REV 13.1:2020
Bar feeder collet must be correct for the size material. Using the wrong collet can cause
production issues. Contact Edge Technologies Parts Department for assistance.
ØA
ØF M5x0.5 ØF M7x0.75 ØF M8x1.0 ØF M8x1.0 ØF M8x1.0 ØF M10x1.0 ØF M10x1.0 ØF M10x1.0
mm in
7.5mm OD 12mm OD 15mm OD 16mm OD 18mm OD 20mm OD 22mm OD 23mm OD
1.6
ICOLT075160 ICOLT120160 ICOLT150160
2
2.4 3/32”
ICOLT075240 ICOLT120240 ICOLT150240
2.5
2.8 7/64”
ICOLT075280 ICOLT120280 ICOLT150280
3
3.2 1/8”
ICOLT075320 ICOLT120320 ICOLT150320 ICOLT200320
3.5
3.6 9/64”
ICOLT075360 ICOLT120360 ICOLT150360 ICOLT200360
3.8
4 5/32”
ICOLT075400 ICOLT120400 ICOLT150400 ICOLT200400
4.4 11/64”
ICOLT075440 ICOLT120440 ICOLT150440 ICOLT200440
4.5
4.6
4.8 3/16”
ICOLT075480 ICOLT120480 ICOLT150480 ICOLT200480
5
5.2 13/64”
ICOLT075520 ICOLT120520 ICOLT150520 ICOLT200520
5.5
5.6 7/32”
ICOLT075560 ICOLT120560 ICOLT150560 ICOLT200560
5.7
5.9
