MINUTEMAN 320
68
REV 13.1:2020
7. Connect adapter (G) to swivel (B) and tighten.
8. Connect adapter (G) to synchronization rod (H) with screws supplied.
9. Gap (I) should be approximately 12.7mm (.500”).Adjust the length of the rod as required.
10. Synch rod should never make contact with bar feeder.
Move lathe Z axis forward and back checking for smooth operation and clearance of
synchronization rod (H), adapter (G) and threaded rod (A).
