MINUTEMAN 320
87
REV 13.1:2020
Warning be sure to use the correct channel set components for a
specific size.
The channel set for the Minuteman contains many pieces that must be placed in certain
locations. The length of the channel section is specific to a region within the channel rail. It is
recommended that 1 channel section at a time is removed and replaced with the conversion
piece. All components with in a channel set is specific to the size of that channel set. Combining
the channel; sets will not work properly and will produce poor bar feeder performance.
For available guide channel sets reference this manual or contact Edge Technologies for the
most up to date information.
