STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 140

STP

LINK

AND

DISPLAY

UNIT

6.2 Display unit

The "display unit" operates the STP pump, confirms the pump status or sets various settings. The

display unit iDT-001 is equipped with an LCD and flat panel switches.

See the Instruction Manual of the "Display unit iDT-001" for the detailed specification and operating

methods.

STP-Link

BRAKE

ACCEL.

STOP

START

NORMAL FAILURE

POWER

DOWN

ENTER

SELECTRESET

98.4

132

122.5

Figure 56 - Display unit iDT-001
