5.2.3 Communication parameter setting
The factory setting of COM1 and COM2 is shown in Table 29. To set communication parameters, use
the STP-Link (optional accessory) or the display unit iDT-001 (optional accessory).
Communication
parameter
Factory setting
PC setting example
Baud rate
9,600 bps
1,200 to 56,000 bps
Bit length
8 bit
7, 8bit
Stop bit
1 bit
1, 2bit
Parity
None
None, Even, Odd
Driver type
COM1
RS232/RS485 single
RS232/RS485 single, RS485 multi
COM2
RS485 single
RS485 single, RS485 multi
RS485ID
*1
1
1 to 127
*1 It is used in RS485 Multi.
Table 29 - Communication parameters
