STP-iXA3306 Series Turbomolecular Pump
3.1.2 Installation area
Leave enough space for the followings in addition to that for the STP pump: (see Figure 9)
Space for maintenance and inspection.
Space for connecting cables.
CAUTION
DO NOT bend the cables excessively and beware of any obstacles when installing the STP pump.
In addition, leave enough space to install other cables without bending them excessively.
Figure 9 - Space around the STP pump
