Double-sided Printing
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 151
7.2.3 Backlit - Head-to-Head - Print Side B
1. After loading the media, align the slits to the edge of the print table.
2. Perform Measure Media.
3. Turn the Backlit illumination ON.
Figure 7-11
4. In the EFI FE, take the mjob from the Done pane to the Printing Queue. Double-
click the mjob to open the Job Settings.
5. In the Job Settings dialog’s Double Side group box, check the Backside check
box, and click OK.
6. Start printing Side B.
Figure 7-12
The printing starts with the Back side Marks and pausing for adjustments.
7. Click Yes. The carriage docks at the home position. You can open the printer’s
cover and check the registration between the front and the back marks.
The Printer Status window opens. The goal is to align the marks of Side B to the
center of the marks of Side A.
