5.2.3 Crash Protector
The carriage is equipped with two crash protectors—one at each end, as shown. If there is an obstruction along the
carriage path, the crash protector is triggered and the printer stops working immediately.
Figure 5-6
Crash Protector
Crash Protector
Crash Protector
1. When a crash occurs, locate the obstruction and remove it. (If necessary,
move the carriage manually.)
2. Click OK to continue printing or HELP to access the relevant documentation.
Figure 5-7
