EFI Pro 32r - Page 90

Figure 5-18 : Test Pattern Before and After Calibration
Before Calibration
After Calibration
Printer Setup
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 90
NOTE: Calibration to zero is the goal, but +/-16 is within acceptable tolerance.
3. Repeat this test until you are satisfied with the result.
