5.2 Setting the reference position
(For detailed instructions refer to Chapter 6.9.1 Setting the Reference Position (Parameter 170)
 Hold down the button and
switch on the controls
 (Until Pos0 show for 1
second)
 Press the E button
 "P0" and a rotating
"u" are displayed
 Turn the handwheel until
the rotating "u" disappears
 Bring the handwheel to
the zero position (needle
up / OT)
 Press the E button
 Turn off
Note: If the rotating "u" does not disappear after 10 rotations, change the direction of rotations.
