11.1 Operator Level
NoteThe preset values indicated apply to mode 0 (Parameter 290 = 0).
For preset values applicable to other modes see table in chapter 11.1 »Preset Values Depending on Mode«.
Parameters
Designation
Unit
Max
Min
Preset
Ind.
000 c2
- Number of stitches of start backtack forward
- Number of stitches of start stitch condensing without
stitch regulator
- Number of stitches of end counting chain suction
Stitches
254
0
2
001 c1
- Number of stitches of start backtack backward
- Number of stitches of start stitch condensing with stitch
regulator
- Number of stitches of start counting chain suction
Stitches
254
0
4
002 c3
- Number of stitches of end backtack backward
- Number of stitches of end stitch condensing with stitch
regulator
- Number of stitches of tape cutter at the start of the
seam
Stitches
254
0
2
003 c4
- Number of stitches of end backtack forward
- Number of stitches of end stitch condensing without
stitch regulator
- Number of stitches of tape cutter at the seam end
Stitches
254
0
2
004 LS
Light barrier compensating stitches
Stitches
254
0
7
005 LSF
Number of stitches of the light barrier filter for knitted
fabrics
Stitches
254
0
1
006 LSn
Number of light barrier seams
15
1
1
007 Stc
Number of stitches for the seam with stitch counting
Stitches
999
0
20
008 -F
A parameter from the technician level is assigned to key 9 on the
V820 control panel
1 = Softstart On/Off
2 = Ornamental backtack On/Off
3 = Start of sewing blocked with light barrier uncovered On/Off
4 = Unlocking the chain On/Off
8 = Backtack repetition On/Off
9 = Multi-backtack / standard backtack
9
1
1
009 LS
Light barrier On/Off
1
0
0
010 SrM
Strobel backtack in mode F-290 =56
0 = End backtack off
1 = Single end backtack on2 = Double end backtack on
3 = Double start and double end backtack on
4 = Simple start backtack and simple end tack on
4
0
0
F
013 FA
Thread trimmer On/Off
1
0
0
014 Fw
Thread wiper On/Off
1
0
0
015 StS
Stitch counting On/Off
1
0
0
017 SAb
Stop for tape cutting at the seam end On/Off
(Function only when overlock mode is active).
1
0
0
018 UoS
0 = Sequence “overlock mode with stop”
1 = Sequence “overlock mode without automatic stop. When the
command “run” is given, the drive runs at the pre-selected
speed. With pedal in pos. 0 or light barrier covered, the
program switches to the next start of a seam without issuing
signals M1/M2.
2 = As with setting “1”. But with pedal in pos. 0 signals M1/M2 will
be issued, and the program switches to the next start of a
seam.
3 = As with setting “1”. But with pedal -2 signals M1/M2 will be
issued, and the program switches to the next start of a seam.
Intermediate stop and sewing foot lifting with pedal in pedal -1
is possible.
4 = If the light barrier is covered during the end count for chain
suction, the program switches immediately to the next start of a
seam. If the end count has been completed and the light barrier
remains uncovered, the drive stops.
5 = Tape cutting at the start of the seam with stop
5
0
0
