Efka AB620A5035 - 2 Scope of Supply; 2.1 Special Accessories

- AB620A5035
- 7 -
2 Scope of Supply
Standard Scope of Supply
1
Direct current motor
DC1200 optional DC1250
1
Electronic control/Power supply unit
AB620A5035N214
1
Set of accessories (standard)
B156
Consisting of:
Plastic bag for B156 + documentation
and
1
Set of accessories
Z55
Consisting of:
37-contact SubminD plug,
potential equalization cord
Option 1
1
Actuator
EB401
and
1
Set of accessories
Z66
Consisting of:
37-contact SubminD plug, tension rod,
potential equalization cord
Additional options
Below table assembly set
Z71 AB6..-DC12.. Below table assembly
Pulse encoder IPG001
Z72 AB6..-DC12.. IPG
NOTE
If there is no metallical contact between drive (motor) and machine head, the potential equalization cord
supplied with the unit is to be wired from the machine head to the terminal provided on the control box!
2.1 Special Accessories
The special accessories available ex works allow the augmentation and enhancement of functions, operating,
connecting, and mounting options.
Since the range of available components is continually expanded, we kindly ask you to contact us in case of
need.
Designation
Material No.
Control panel Variocontrol V810
5970153
Control panel Variocontrol V820
5970154
Control panel Variocontrol V860
5990164
Reflection light barrier module LSM002
6100031
Hall sensor module HSM001
6100032
Pulse encoder IPG001
6100033
Adapter cord for the connection of light barrier module and/or Hall sensor module
HSM001 and/or pulse encoder IPG001
1113229
Extension cable approx. 1000 mm long for commutation transmitter DC12.. + DC15..
1113151
Extension cable approx. 1000 mm long for Netz DC12.. line + DC15..
1113931
Potential equalization cord 700 mm long, LIY 2.5 mm
2
, gray, with spades on both
sides
1100313
Foot control type FB302B with three pedals for standing operation, with
approx. 1400 mm connecting cable and plug
4170025
Fitting piece for position transmitter
0300019
Knee switch type KN19 (pushbutton) with cord of approx. 450 mm length and
western plug (RJ11)
5870021
Knee switch type KN20 (pushbutton + selector switch ) with cord of approx.
1640 mm length and Western plug (RJ11)
5870022
Adapter set for DC12. + DC15.. on PEGASUS model W600
1113125
Adapter set for DC12. + DC15.. on PEGASUS Ex/Ext
1113126
Adapter set for DC12. + DC15.. on PEGASUS model W1500N, W1600
1113647
Undertable mounting kit for DC1200/DC1250
1113956
Undertable mounting kit for DC1500/DC1550
1113427
