11 Timing Diagrams
Mode 0 (lockstitch)
Mark
Function
Parameters
Control
V810
V820
FAm
Mode 0
Double start backtack with stitch correction
Double end backtack with stitch correction
On
On
290 =0/27
Key E
Key +
Key 1
Key 2
Key 1
Key 4
n1
n2
n3
n4
n7
Positioning speed
Maximum speed
Start backtack speed
End backtack speed
Trimming speed
110
111
112
113
116
c2
c1
c3
c4
t8
t9
t1
t3
t4
t5
t6
t7
Start backtack stitches forward
Start backtack stitches backward
End backtack stitches backward
End backtack stitches forward
Start backtack stitch correction
End backtack stitch correction
Delay until speed release after start backtack
Start delay from lifted sewing foot
Full power of sewing foot lifting
Pulsing of sewing foot lifting
Thread wiper ON period
Sewing foot switch-on delay after thread wiper
000
001
002
003
150
151
200
202
203
204
205
206
