 Speed selection pedal controlled / n5 during the light barrier compensating stitches using parameter 192.
The light barrier compensating stitches can be programmed and varied using the above parameters directly on
the control or on a connected V810/V820 control panel.
For fast operator information (HIT) when using the V820 control panel, the value of the function switched on
using key 3 can be displayed for approx. 3 seconds. During this time, the value can be varied directly by
pressing key + or -.
When using a V820 control panel, direct access by means of the function key (key 9) is possible.
Function with control panel
Parameters
Start of sewing blocked with light barrier uncovered On/Off
(-F-)
008 =3
7.25.3 Reflection Light Barrier LSM002
Sensitivity setting:
Set minimum sensitivity depending on the distance between light barrier and reflection area (turn potentiometer
as far as possible to the left).
 Potentiometer directly on the light barrier module
Mechanical orientation:
Orientation is facilitated by a visible light spot on the reflection area.
7.25.4 Automatic Start Controlled by Light Barrier
This function is not possible when parameter F-290 =8 or 9 (modes 8 and 9)!
Function
Parameters
Delay of automatic start
Automatic start On/Off
Light barrier sensing uncovered
Start of sewing blocked with light barrier uncovered
(ASd)
(ALS)
(LSd)
LSS
128
129
131
132
This function enables an automatic start of the sewing operation as soon as the light barrier senses the insertion
of fabric.
Prerequisites for the operation:
 Parameter 009 = 1 Light barrier On
 Parameter 129 = 1 Automatic start On
 Parameter 131 = 1 Light barrier sensing uncovered
 Parameter 132 = 1 No start of sewing with light barrier uncovered
 The pedal must be kept pressed forward at the seam end.
For safety reasons this function is enabled only after a normal start of sewing. The light barrier must be covered
as long as the pedal is in position 0. Then press the pedal forward. This function is disabled when the pedal is
no longer pressed forward after the seam end.
7.25.5 Light barrier filter for knitted fabrics
Function
Parameters
Number of stitches of the light barrier filter
Light barrier filter On/Off
Light barrier sensing uncovered or covered
(LSF)
(LSF)
(LSd)
005
130
131
The filter prevents premature enabling of the light barrier function when sewing knitted fabrics.
 Enabling/Disabling of the filter using parameter 130
 The filter is not active if parameter 005 = 0
 Adaptation to the mesh is possible by varying the number of filter stitches.
 Knitted fabric sensing with light barrier
- Uncovered

covered,
if parameter 131 = 0.
- Covered

uncovered,
if parameter 131 = 1.
