Efka AB620A5035 - Technical Level (Code No. 1907)

- AB620A5035 Instruction Manual
- 83 -
11.2 Technical level (Code no. 1907)
Parameters
Designation
Unit
Max
Min
Preset
Ind.
100 SSc
Number of softstart stitches
Stitches
254
0
2
101 EvA
Switch-on start backtack for the backtacking solenoid in
the initial backtack
ms
255
0
43
102 AvA
Power-off start backtack for the backtacking solenoid in
the initial backtack
ms
255
0
4
103 EvE
Switch-on start backtack for the backtacking solenoid in
the final backtack
ms
255
0
43
104 AvE
Power-off start backtack for the backtacking solenoid in
the final backtack
ms
255
0
5
108 PEr
Stop position of the ornamental backtack
1 = Position 1 leading
2 = Position 2 leading
3 = Position 1 trailing
4 = Position 2 trailing
5 = Position 3 leading
6 = Position 3 trailing
6
1
1
109 n13
Speed of manual backtack
RPM
9900
200
1500
110 n1
Positioning speed for threading (mode 66)
RPM
390
70
200
111 n2
Upper limit setting range of the maximum speed
RPM
9900
n2_
5000
112 n3
Start backtacking speed
RPM
9900
200
1200
113 n4
End backtacking speed
RPM
9900
200
1200
114 n5
Speed after light barrier sensing
RPM
9900
200
1200
115 n6
Softstart speed
RPM
9900
70
500
116 n7
Trimming speed
RPM
700
70
200
117 n10
High lift for walking speed limitation
RPM
9900
400
1000
118 n12
Automatic speed for stitch counting
RPM
9900
400
3500
119 nSt
Speed stage graduation
1 = Linear
2 = Slightly progressive
3 = Highly progressive
3
1
121 n2
Lower limit setting range of the maximum speed
RPM
n2_
200
400
122 n9
Limited speed n9
RPM
9900
200
2000
123 n11
Limited speed n11
RPM
9900
200
2500
125 bot
Speed limitation using ext. potentiometer (minimum value)
RPM
Pa.25
0
200
126 Pot
Function “speed limitation using external potentiometer”
0 = Function “external potentiometer” Off
7 = Lift-dependent speed limiting with potentiometer
(if parameter 911= 912).
7
0
0
127 AkS
Acoustic signal for V8xx ON/OFFI
1
0
0
128 ASd
Start start backtack, when command “start” is given by
covering the light barrier (see parameter 129)
ms
2000
0
0
129 ALS
Machine start by covering the light barrier (only in conjunction with
parameter 132 = 1)
0 = Function Off
1 = Light barrier covered  pedal forward (>1) machine run pedal
controlled.
2 = Pedal forward (>1)  light barrier covered machine run  pedal
controlled.
3 = Light barrier covered  machine run at automatic speed n12
(without pedal)
4 = Pedal forward (>1)  light barrier covered machine run pedal
controlled.
5 = Light barrier covered  machine run at automatic speed n12
(without pedal)
Attention! If 129 = 3, the machine starts immediately after covering
the light barrier without influence by the pedal! It can be stopped only
by uncovering the light barrier or by machine run blockage!
If machine run blockage is disabled, the machine starts immediately
even if the light barrier is still covered!
6 = The same as 3, run without pedal when covering the light curtain,
however start up only when FI is lowered.
3
0
0
130 LSF
Light barrier filter for knitted fabrics
1
0
0
131 LSd
0 = Light barrier sensing “covered”
1 = Light barrier sensing uncovered
1
0
1
132 LSS
0 = Machine start possible with light barrier uncovered or covered.
1 = Machine start blocked with light barrier uncovered if parameter
131 = 1.Machine start blocked with light barrier covered,
1
0
1
