3 = Switched off when the foot is lifted or locked.
Parameters
Designation
Unit
Max
Min
Preset
Ind.
041 EZP
Special pedal function Single stitch / Full stitch
0 = Function Off
1 = Single stitch (assuming needle up to needle down). Afterwards
alas a complete hand wheel rotation in speed n9)
2 = Full stitch (a complete hand wheel rotation in speed n9)
3 = Speed limitation up to F-042
2
0
0
042 GrP
Pedal travel forwards for detection of the special pedal
function
%
100
0
40
049 KML
Coupling motor running (Kopplung MotorLäuft) signal (F-290=7)
=0 OFF
=1 Coupling with pedal Mi1 & pedal Mi2 in the seam
=2 Coupling with pedal Mi1 & pedal Mi2 outside of the
seam
=3 Coupling with pedal Mi1 & pedal Mi2 in and outside of
the seam
3
0
0
051 dPd
Time for detection of the special pedal function
ms
2550
0
100
082 DDr
Suck stitches to waste
Stitches
254
0
25
D
083 tDr
Time sucking waste
ms
5000
0
0
D
084 Mle
Stitches for motor ECO On
Stitches
254
0
5
085 Mla
Stitches for motor ECO runs down
Stitches
254
0
5
086 vct
Counted forward section in manual ornamental backtack On/Off
1
0
1
087 chr
0 = Manual backtack at speed n13 (Parameter 109)
1..255 = Manual ornamental backtack at speed n9
(Parameter 122)
Stitches
255
0
0
088 kla
Stitches for clamping the seam start (mode 68)
Stitches
20
0
3
090 wAr
Repetition of the start/ multiple backtack
255
0
3
091 wEr
Repetition of the final/multiple backtack
255
0
3
092 Fwr
1 = Backtack repetition On/Off
2 = Repetition of the start backtack with automatic cutting. No end
backtack is done.
2
0
0
